1.2 mm Water Curtain Electrostatic Wet Paint Booth
| Brand | Tasarımak |
|---|---|
| Model Type |
T-SPYBK01 |
1.2 mm Water Curtain Electrostatic Wet Paint Booth
Design
The reasons for the prohibition of open area Wet Paint applications by many advanced countries in the world can be shown as products such as rasp, polyurethane, adhesive heavily polluting the environment.
With the advancement of technology, one of the growing areas in recent times is the Wet Paint Applications carried out in enclosed spaces, the reasons for the increasing prevalence of Wet Paint Application in enclosed spaces due to reasons such as rising standards, cost analysis, job safety, and environmental conditions.
|
Production Method |
Manufactured in disassembled form |
|
Panels |
1.2mm Galvanized |
|
Waterfall Type |
Openable from the front end hinged type |
|
Waterfall Suction |
Sucks from the bottom and middle parts. |
|
Bottom Pool |
2mm st 37 Galvanized |
|
Bottom Pool Height |
360mm |
|
Pump Type |
Centrifuge Type Standard Brand |
|
Pump Seal |
Mechanical Sealed |
|
Pump Filter |
Sliding type Stainless 100 micron |
|
Valves |
Butterfly type and spherical valve |
|
Piping |
PPRC, PVC or Galvanized |
|
Exhaust Wash |
Circular type special wash 95% efficient |
|
Nozzles |
Sprig Systems |
|
GRIDS |
700*700*30 galvanized coated 40*40 spaced grid |
|
Water Discharge |
Done with Main Pump |
|
Lighting |
500 lux fluorescent type waterproof luminaire |
|
Lighting Class |
ZONE 3 EXPROF |
|
Electrical Materials |
SIEMENS / SCHNEİDER |
|
Cables |
TSE & CE |
|
Fan Type |
Dynamic and Static Balanced Radial Fan |
