1 Litre Semi-Automatic Packaging Filling Machine

Technical Specifications

✓ Number of filling cylinders in the machine: 1
✓ The machine is a volumetric filling machine that operates with a pneumatic system.
✓ Weight adjustment is easily set and recorded with a turning lever and counter.
✓ The product to be filled is directly taken from the production tank.
✓ Thanks to the high surface smoothness and argon welding technology, it prevents bacterial growth and contamination.
✓ Sealing elements are made of teflon, viton, or polyethylene material according to the chemical properties and temperature of the material to be filled.
✓ Parts on the machine are connected with tri-clamp (clamps).
✓ Nozzle, valve, and filling piston are designed for easy cleaning.
✓ Can be easily disassembled without using any tools.
✓ Interchangeable filling nozzles for liquid, viscous, or granular products are available.
✓ There is a filling tray platform to place the packages during the filling process, which can be easily adjusted up and down according to the height of the package.
✓ The machine stands on a stainless steel frame supported by 4 wheels.
✓ Thanks to its wheels, it can be easily and quickly made ready for filling anywhere.
✓ Tabletop and wheeled models are available.
✓ The machine operates with 6-8 bar air.
✓ No electrical and electronic systems are used in the machine.
✓ All surfaces that come into contact with the product are made of 316 quality stainless steel.
✓ The outer surface, housing covers, and legs are made of 304 quality stainless steel and aluminum.

Areas of Use

Food and Beverage:
Olive oil, Sunflower Oil, Boza, Turnip Juice, Vinegar, Liquid sauces, Salsa, Meze, Sauce, Ayran, Yogurt Jam, Honey, Marmalade, Pomegranate Molasses, Fruit Juice, Kefir, Ayran, Lemonade etc…

Chemical and Cosmetic:
Liquid detergent, Liquid hand soap, Liquid dish detergent, Gel detergent, Softener, Cologne, Bleach, Disinfectant, Shampoo, Liquid fertilizer, Arabic Soap, Shampoo, Lotion, Cream, Gel, Medical Liquids etc…

Mineral Oil:
Motor oil, Fuel additive, Antifreeze, all mineral oils, etc…

Paint:
Paint, Solvent, Thinner, Solvent-based paint, etc…

Filling capacity numbers:

SINGLE PISTON
WEIGHT RANGE

5 – 50 ml                   = 2000 pieces
15 – 150 ml                = 1800 pieces
50 ml – 500 ml       = 1500 pieces
50 ml – 1,000 ml    = 800 pieces
