10-18 Ton / Hour Color Sorting Machine
| Brand | Milleral |
|---|---|
| Model Type |
MSR-10 |
Description
Milleral MSR-10
10-18 Ton / Hour Color Sorting Machine
| Model | MSR-02 | MSR-03 | MSR-04 | MSR-05 | MSR-06 | MSR-07 | MSR-08 | MSR-10 |
| Capacity (t/h) |
1-4 | 2-6 | 3-8 | 5-10 | 7-12 | 8-14 | 9-16 | 10-18 |
| Separation Accuracy (%) | 99.99 | |||||||
| Revolution Rate | >120:1 | |||||||
| Power (kW) |
1.3 | 1.9 | 2.4 | 3 | 3.6 | 4.1 | 4.7 | 5.8 |
| Feeding Voltage (V) |
220 V / 50 Hz | |||||||
| Air Pressure (MPa) |
0.5-0.8 | |||||||
| Air Consumption (m3/min) |
0.5-1 | 0.8-1.5 | 1-2 | 1.3-2.1 | 2-3.5 | 2.5-4.3 | 3-4.5 | 5-6.5 |
| Dimensions (mm) |
1207x1460x1960 | 1207x1460x1960 | 1835x1460x1960 | 2149x1460x1960 | 2463x1460x1960 |
2777x1460x1960
1525 |
3091x1460x1960 | 3719x1460x1960 |
| Weight (kg) |
700 | 860 | 1020 | 1187 | 1332 | 1525 | 1686 | 2047 |
