10 m³ Solid Fertilizer Spreading Trailer

The Tutkun Fertilizer Spreading Trailer allows for the homogeneous distribution of fertilizer loaded onto the field. The specially designed suspension system on the chassis prevents oscillations caused by the loaded machine from reaching the tractor. This provides a more comfortable driving experience. The specially designed vertically placed spreaders, along with the added spreader blades, ensure the fertilizer is spread evenly across the field. Additionally, the specially designed transmission system that facilitates the transfer is designed to withstand high powers and operate smoothly for many years.

Model	KGD-4	KGD-5	KGD-6	KGD-10
Length	510 cm	510 cm	565 cm	700 cm
Width	210 cm	210 cm	210 cm	215 cm
Height	204 cm	230 cm	207-257 (with addition) cm	230 cm
Weight	2200 kg	2345 kg	2650 kg	3920 kg
Conveyor	Hydraulic	Hydraulic	Hydraulic	Hydraulic
Capacity (m³)	4 m³	5 m³	6 m³	10m³
Capacity (ton)	5 tons	6 tons	7 tons	12 tons
Conveyor Cover	Hydraulic	Hydraulic	Hydraulic	Hydraulic
Helix Movement	Power Take-Off- PTO	Power Take-Off- PTO	Power Take-Off- PTO	Power Take-Off- PTO
Number of Helix Gears	3	3	3	3
Number of Conveyor Gears	1	1	1	1
Safety System	Friction Shaft	Friction Shaft	Friction Shaft	Friction Shaft
Number of Helices	2	2	2	2
Conveyor Type	13 mm Heat Treated Chain	13 mm Heat Treated Chain	13 mm Heat Treated Chain	13 mm Heat Treated Chain
Axle Type	Single Axle	Single Axle	Single Axle	Double Axle / Tandem Scissors
Tire Size	[ PHONE HIDDEN ]	[ PHONE HIDDEN ]	[ PHONE HIDDEN ]	[ PHONE HIDDEN ]
Minimum Required Power	50 HP	55 HP	55 HP	75 HP
Power Take-Off Speed	540	540	540	540
Fertilizer Spreading Width	15 m	15 m	15 m	15 m
