100 Kg Lid Mixer Meat Cooking Pot Machine

100 Kg Lid Mixer Cooking Pot

Areas of Use

Made entirely of 304/316 Quality Stainless Steel

Can be manufactured as an open type without a lid upon request

100 Kg Net Mixing Capacity

In slaughterhouses and meat processing facilities

In roasting facilities

For boiling meat products

For melting animal fats

Used multifunctionally as a roasting and boiling pot.

Technical Specifications

1. BODY THICKNESS 6 MM
2. STEAM JACKET COIL THICKNESS 3MM
3. INSULATION THICKNESS 1.5 MM
4. TOP COVER THICKNESS 1.5  MM
5. LEG 40 X 60  3 MM PROFILE
6. OUTER BODY COATING  1.5 MM
7. MIXER SHAFT 35 MM

I.      MIXER BLADES  40 X 10 MM

1. INSULATION MATERIAL 50 MM   STONE WOOL
2. STEAM INLET 1 /1  MM
3. DIGITAL MIXER TIME ADJUSTMENT
4. PNEUMATIC TOP COVER LIFTING PISTONS 50X200
5. WATER AND OIL DRAIN VALVE DN 50 PN 63
6. PNEUMATIC PISTON CONTROL ARM JELPC 4H330C
7. 2 PIECES OF TOP COVER STEAM DRAIN OUTLETS 120X170 MM
8. 40X60 4 PIECES OF PLASTIC LEG CAPS
9. BEARINGS FOR MIXER SHAFT BEARINGS 35 MM
10. TOP COVER SAFETY SWITCH
11. TOP COVER LIFTING ARM 27X2 MM PIPE
12. MOTOR REDUCER      60 BODY  1.1 KW 16 Min
13. ELECTRIC CONTROL PANEL
14. DIGITAL TIMER RELAY

U.MACHINE DIMENSIONS :

WIDTH : 1100  mm

LENGTH  : 1100  mm

DEPTH : 500  mm

TOTAL HEIGHT : 1500  mm
