ErichHahn MT-100 Industrial Mobile Tank

ErichHahn MT mobile tanks are designed to actively heat and store heavy oil, providing transport while preserving its quality. Mobile tanks can also be used as process tanks in oil, gas, chemical, food, and other industries. They occupy a small area and can be easily transported by road.

ErichHahn MT Advantages

MT-М series tanks are additionally equipped with a mixer, instrumentation, control panel, heating system, insulation, and service platforms.

Control Cabin

The tank is supplied with a local control cabin. This cabin allows monitoring and controlling instrumentation in the field or can provide remote control through integration with the APCS.

Mobile Tank Options

• Electric heaters to increase product temperature
• Electric actuator covers for remote process control

ErichHahn MT-100 Technical Specifications

Instrumentation
Operating environment	Viscous and solidifying liquids
Max. temperature of the operating environment, °C	200
Tank capacity, m³	100
Inner diameter, mm	3000
Height, mm	16410
Weight, kg	13000
Tank loading type	Top
Tank unloading type	Bottom
Overflow protection device	Provided
Mixer
Vertical	–
Steel structure parameters
Number of tank courses	9
1-2. course thickness, mm	8
3-4. course thickness, mm	6
5-11. course thickness, mm	5
Roof covering thickness, mm	5
Base thickness, mm	10
Insulation
Wall insulation thickness, mm	150
Roof insulation thickness, mm	200
Coating material	Polymer-coated steel sheet
Heating system
Main heating
Oil heater	Provided
Heat transfer fluid	Hot oil
Oil pipe connection, mm	50
Max oil temperature at 0.6 MPa, °C	200
Extra heating
Heating elements	–
Level gauge	Provided
Maximum level alarm	Provided
Sampling device	Provided
Temperature gauge (for heavy oil)	Provided
Electric actuator cover valve, DN, mm	150 (optional)
Bimetallic thermometer	Provided
Ventilation pipe	Provided
Control panel	Provided
Country of origin	Turkey

Brand	ErichHahn
Model Type	MT-100
