100 Ton Tank Welding Converter

YKS BSRKROT 090-100 Tank Welding Converter

YKS BSRKROT 090-100 is a professional welding rotator system that provides high carrying capacity and safe operation in the turning operations of heavy and large diameter tanks, boilers and cylindrical workpieces. This model, which can carry loads up to 100 tons without any problems, is a preferred solution especially in tank manufacturing, power plants, pressure vessel production, pipeline construction and heavy industry applications.

Thanks to its self-adjusting structure, the weight distribution and diameter variability of the workpiece are automatically balanced. This feature both increases operator safety and ensures that the workpiece is rotated at the correct center. It does not require any extra equipment or operations during adjustment; It can cover wide diameter ranges quickly.

All capacities between 10 tons and 150 tons are offered in standard production. Upon request, special production up to 250 tons capacity can be made.

YKS BSRKROT 090-100 Standard Features

• Durable PU coating wheels

• Bolted diameter adjustment system

• Adjustable rotation speed

• 5 meter cable hand control

• Digital speedometer on dashboard

• Powerful AC motor

• Stop group that prevents axial sliding of the workpiece

• High temperature resistant special wheel design

• Motorized wheel axis distance adjustment (Driver: motorized, Idler: manual)

• Motorized walking system

• Chassis – brush group

• Synchronous working feature with column-boom systems

These features increase stability, especially in high tonnage tanks, and make the turning process safe.

YKS BSRKROT 090-100 Technical Specifications

The table below shows all technical data of the BSRKROT series from 5 tons to 100 tons.
The features of the 100 ton capacity YKS BSRKROT 090-100 model are stated in bold in the table.

Featured Advantages

• High carrying capacity of 100 tons

• Automatic centering with self-adjusting wheel structure

• Possibility of working in a wide diameter range

• Long life with durable polyurethane wheels

• Safe and stable turning in large tanks and boilers

• Adjustable speed control and digital display

• Full compatibility with column-boom systems

• Versatile use in heavy industry
