10,000 Kg / Day Block Ice Machine
| Brand | Mayso Soğutma |
|---|---|
| Model Type |
MYBZ-BLK / 10 T |
10,000 Kg / Day Block Ice Machine
The MYBZ-BLK / 10 T model Block Ice Machine produced by Mayso Cooling is a high-efficiency ice production device that operates with fresh water and has a capacity of 10,000 kg/day. This machine produces block ice within brine tanks, making a difference in the industry in terms of efficiency and durability.
Features:
-
Capacity: Provides large-scale ice production with a capacity of 10,000 kg/day.
-
Block Ice Production: Block ice is produced by cooling brine water in an environment of -15°C using fresh water.
-
Electricity and Water Savings: Unlike other competing machines, it stands out with low energy consumption and water efficiency.
-
High Efficiency: Our machines provide high-efficiency ice production with less energy and water thanks to advanced technology.
Technical Specifications:
-
Capacity: 10,000 kg/day ice production capacity
-
Ice Type: Block Ice
-
Water Type: Production is done using fresh water
-
Cooling System: Block ice production with brine cooling technology
Advantages:
-
Energy Savings: Electricity consumption is kept to a minimum, reducing operating costs.
-
Water Savings: Produces a large amount of ice using a small amount of water, environmentally friendly.
-
Stable and Reliable Performance: Continuous high efficiency is achieved thanks to its design resistant to temperature and water conditions.
-
Various Capacity Options: Provides suitable solutions for every size of operation with capacity options ranging from 250 kg to 10,000 kg.
Areas of Use:
-
Food Industry: Used in cooling, transportation, and storage processes.
-
Maritime and Fishing: Effective solution for cooling and transporting fish and seafood.
-
Large Cooling Needs: Used in industrial cooling areas and large storage facilities.
Block Ice Machines offer capacity options ranging from 250 kg to 10,000 kg, providing solutions for all types of industrial cooling needs. You can contact us for more information and to request a quote.
Mayso Cooling MYBZ-BLK / 10 T Technical Description
|
Machine Model |
MYBZ-BLK / 10 T |
|---|---|
|
Daily Ice Capacity |
10,000 Kg / 24h |
|
Block Ice Weight |
20 Kg |
|
Number of Molds |
168 |
|
Daily Number of Ice Molds |
504 Pieces |
|
Ice Production Time |
7 Hours |
|
Ice Exit Temperature |
-10 / -12 °C |
|
Ice Color |
White Matte |
|
Water Inlet Temperature |
20 °C |
|
Cooling Capacity |
56,500 Watt |
|
Refrigerant |
R404A |
|
Compressor Type |
Semi-Hermetic |
|
Total Power Consumption |
43.5 kW |
|
Compressor Power |
32.5 kW |
|
Condenser Fan Power |
8 kW |
|
Mixer Motor Power |
3 kW |
|
Energy Input |
3P/380V/50Hz |
|
Total Amperage |
77 Amp |
|
Evaporator Type |
Copper Coil Immersion |
|
Evaporator Temperature |
-20 °C |
|
Condenser Temperature |
45 °C |
|
Condenser Cooling Type |
Air-Cooled |
|
Ice Freezing Type |
Brine Water |
|
Machine Dimensions |
116x315x150 cm |
|
Machine Weight |
4,000 kg |
