100×160 150w Camera Laser Cutting Machine

Model

Vulcan FC 500VC Flatbed Cutting and Creasing Machine

Configuration

Digital servo system, flat platform

Media Holding Method

Vacuum suction

Maximum Cutting Speed

700 mm/s (10 – 700 mm/s)

Cutting Pressure

Tool 1: Max. 5.88 N (600gf), Tool 2: Max. 5.88 N (600gf)

Effective Cutting Area

495x685mm

Mountable Media (Y-axis direction)

640mm

Minimum Character Size

5mm square

Mechanical Resolution

0.005mm (Sµm)

Programmable Resolution

HP-GL: 0.025mm

Repeatability

0.1mm

Standard Interface

USB2.0 (Full Speed) / U-Disk / Ethernet

Memory

32MB

Command Sets

HP-GL

Number of Tools

2

Tool Types

Cutter blade / Pen / Creasing / Engraving Tool

Working Screen

4.3-inch touch LCD

Power Supply

100 to 240V AC, 50/60 Hz (Auto-switching)

Power Consumption

Max. 150VA (machine), Max. 550W (vacuum pump)

Operating Environment

Temperature: 10 to 35°C (50 to 95°F)

Humidity

35 to 75% RH (non-condensing)

External Dimensions

981 (W) x 977 (L) x 1047 (H) mm

Packaging Dimensions

115x110x61 cm (machine) / 53x45x39 cm (vacuum pump)

Gross Weight / Net Weight

113kg – 62kg (machine) / 25kg – 23kg (vacuum pump)

Compatible Operating Systems

Windows and Mac
