115 Ton Hydraulic Double Piston Combined Shears

KMH 115 – HYDRAULIC DOUBLE PISTON COMBINED SHEARS

STANDARD EQUIPMENT

PUNCHING DIE

• Maximum thickness diameter: Ø 34 × 26 mm

• Diameter × thickness (Ø × t): Ø 55 × 16 mm

• Maximum diameter thickness: Ø 110 × 5 mm

• Stroke length: 80 mm

• Number of strokes: 25

• Groove depth: 355 mm

• Working height: 1110 mm

FULL MATERIAL SHEARS

• Round / Square: Ø 55 / 50 mm

ANGLE IRON CUTTING SHEARS

• Vertical angle iron (90°): 150 × 150 × 16 mm

• Inclined angle iron (45°): 80 × 10 mm

• Working height: 1215 mm

SHEET METAL SHEARS (BLADE CUTTING)

• Flat sheet: 380 × 25 mm

• Flat sheet: 600 × 15 mm

• Blade length: 610 mm

• Inclined cut: 120 × 15 mm

• Working height: 935 mm

CHANNEL CUTTING

• Material thickness: 13 mm

• Width: 60 mm

• Depth: 100 mm

• Working height: 935 mm

OPTIONAL EQUIPMENT

SPECIAL DIES

• U–I profile blades (UPN–IPN): 200 × 90 mm

• T profile blades: 120 × 13 mm

SPECIAL CHANNEL TOOL

• 100 × 100 × 13 mm

V BENDING

• Blade bending (max.): 250 × 22 mm

• Sheet bending (max.): 700 × 3 mm

PUNCHING IN CHANNEL SECTION

• Jaw depth: 125 mm

• Sheet punching: Ø 38 × 12 mm

TECHNICAL SPECIFICATIONS (KMH 115)

• Motor power: 11 kW

• Pressure: 115 tons

• Machine weight: 2920 kg

• Machine dimensions (W × D × H): 2040 × 950 × 2180 mm

GENERAL EQUIPMENT AND STRUCTURE

• 2 separate hydraulic pistons and 2 separate foot controls allowing two people to work simultaneously

• Adjustable piston stroke distance for continuous operation

• Central lubrication system

• Electric switch rear support

• Working lamp

• On the same body, 5 separate workstations:

  • Ø26 mm punch and die / standard hole drilling apparatus

  • Full round and full square cutting blade set

  • Angle cutting blade set

  • Blade and sheet cutting blade set

  • U-channel opening blade set
