12-Piece Fully Automatic Concrete Brick Paving Stone Machine

Yontar KPM-1036-TS-2 12-Piece Fully Automatic Concrete Brick Paving Stone Machine

Yontar KPM-1036-TS-2 General Features

PM 1036-TS is a fully automatic single-layer production machine. It produces concrete elements such as paving stones, grass stones, curbs, rain gutters, and slope stones.

– The product quality is high and the cycle time is short.
– The locking of the outer mold is ensured by pneumatic bellows cylinders. This allows for a uniform vibration distribution in the mold.
– The vibrator motors are operated via a frequency-controlled speed driver. Thus, the frequency and power of the vibration can be adjusted according to the type of stone produced via the control panel.
– The products are stacked on the shipping pallet with a transfer robot.
– Footless pallets are used in KPM 1036 TS-2 and KPM 1036 TS-4 types and they are manufactured with finger cars.
– All valves and pumps in the hydraulic unit are of PARKER (Germany) brand.
– Proportional valves have been used in all important movements.

Yontar KPM-1036-TS-2 Technical Specifications
