15 Ton / Hour Horizontal Waste Baler Press



50 TON FRONT-COVERED HORIZONTAL TYPE PAPER PRESS
Bale dimensions      100cm x 110cm x 140 CM
Chamber dimensions (width x length x height)    110 * 110 x 110cm
Machine dimensions (width x length x height)    160 x 600 x 180 cm
Bale weight Paper     600-800kg
Idle processing time    40-45 seconds
Capacity    10 – 15Ton / 8 hours
Main cylinder compression pressure    50 Ton
Working pressure    200 -250 Bar
Main motor power    18.5 KW
Hydraulic oil tank capacity    400Lt
front cover system opens and closes with hydraulic cylinder
PLC screen control
