1500 Kg Load And Personnel Exterior Elevator

Technical Specifications:

• Carrying Capacity: 1500 kg

• Maximum Height: 200 m

• Column Dimensions: 500x500x1490 mm

• Vertical Column Weight: 55 kg

• Connection Interval: 6 m

• Elevator Speed: 24 m/min

• Cabin Dimensions: 1250 x 2000 x 2250 mm

• Supply Voltage: 380/50 Volt/Hz

• Motor Power: 2×7.5 Kw

• Current: 63 A

Safety and Comfort:

The 1500 Kg Load and Personnel Elevator complies with high safety standards. Features such as speed-adjustable brake system, emergency stop button, low and high voltage protection device ensure the safe and smooth operation of the elevator. Additionally, it offers quick intervention in case of emergencies with manual lowering lever and emergency siren system.

User-Friendliness:

This elevator is user-friendly with easy installation and disassembly features. It provides comfortable use with ergonomic door design, smooth start and stop system, and spacious cabin dimensions. The modular cabin design allows installation both inside the shaft and outside the building.

Performance and Durability:

The 1500 Kg Load and Personnel Elevator is durable and long-lasting with its strong motor structure and high-strength tower and body design. Capable of reaching heights up to 200 meters, this elevator provides fast and efficient transportation at a speed of 24 m/min. Possible malfunctions can be easily detected and fixed with the electrical fault display.

The 1500 Kg Load and Personnel Elevator is an excellent solution for those seeking high performance and safety in construction sites, high-rise buildings, and industrial areas. Standing out with its high carrying capacity and powerful motor power, this elevator is preferred for its easy installation and user-friendliness. It offers long-lasting use with its durable structure and safety features. Contact us for more information and ordering.
