1600 Lt Paint Mixer

1600 Lt Paint Mixer

Itas Machine DD2000 1600 liter paint mixer offers high capacity and reliable performance in industrial production processes. This mixer, used in many areas requiring dispersion and homogeneous mixture, provides effective mixing of powder and liquid. It can be used in the production of industrial materials such as paint, ink, varnish, pigment paste and various petrochemical products.

The mixed rotation feature of the mixer allows the user to precisely control the mixing process. Thanks to the speed control frequency converter, mixing rotation can be adjusted at the desired speed. Additionally, the hydraulic lift feature makes the mixer easier to use and increases various functionality.

Optional features include explosion-proof systems, vacuum application, automatic control systems and speed control. These features make users’ production process safer and more efficient.

Mixer Features:

Mixed Return:This mixer can be controlled with a speed control frequency converter as well as mono speed. The frequency converter used is a heavy industrial model capable of delivering more power than the rated power of the motor for short periods. Mixing rotation can be adjusted between 0 RPM and 1500 RPM according to standard factory settings.

Hydraulic Lift:This mixer can mix upwards and downwards at any desired height. An electro-hydraulic system is integrated into the body structure. On some models, it is possible to rotate the body 360 degrees and service the surrounding boilers.

Optional Features:Some optional features you can add to your mixer include explosion-proof systems in ATEX Zone 1 EEx dIIB T4 standards, vacuum application, boiler scraper, semi or fully automatic control systems, PLC control system, automatic lifting and lowering system according to the product level in the boiler and speed control.

These features offer a variety of possibilities to improve the performance and expand the functionality of your product.

“Itas Machinery DD2000 paint mixer offers a reliable solution in industrial production and meets large-scale production needs with its large capacity.”

Features:

• Floor mixers
• Use of mobile boilers
• Production of medium to high viscosity products
• Production capacity between 30-5000 liters
• Engine power up to 5.5-160 kW
• Modern frequency converter technology or mechanical DOĞTAŞ belt pulley drive system
• Height adjustable dispersion blade

• Mixer bowl made of carbon steel and stainless steel
• Double suction disc
• vacuum application
• Container wall scraper (rotary)
• Platform balance
• Cover systems
• Temperature measurement and control
• ATEX according to protection system Ex II 2 G c IIB T3 for category 2G (zone 1)
• ATEX according to protection system Ex II 2/- D c IIB T3 for category 2D (zone 21) in the mixing vessel
• ATEX zone 0
• Semi and fully automatic PC/PLC control with recipe control (DD-MIXING-CONTROL®)

Itas Machinery DD2000 Technical Information
