2-Cavity 10 Liter Fully Automatic Water PET Bottle Blowing Machine

Brand Mucitler Makina
Model Type

ESFA2-MCV-MS10lt

Description

2-Cavity 10 Liter Fully Automatic Water PET Bottle Blowing Machine

Mucitler Makina ESFA2-MCV-MS10LT

The ESFA2-MCV-MS10LT developed by Mucitler Makina is designed specifically for facilities producing large volume water bottles, and is a fully automatic PET blowing machine with 2 cavities. This powerful system offers high efficiency and consistent quality in the production of 10-liter bottles.

This model, which can produce 1300 pieces of 10-liter bottles per hour, is a reliable solution for large volume PET packaging production. The bottle volume can be adjusted from 6 cc to 10 liters and works with preforms that have a 48 mm neck diameter. This provides flexible production options for both water filling facilities and different liquid packaging.

Technical Specifications:

  • Lamp Heating System:
    Standard oven system with 10 rows of lamps provides equal and effective heat distribution. It is offered with an optional 12-row option as needed.

  • Motor Powers:

    • 4 kW Mold Closing

    • 2 kW Oven Rotation

    • 2 kW Preform Feeding

    • 2 kW Stretch

    • 1.2 kW Robot Systems

  • Oven Heating Capacity: 120 kW

  • Cooling Requirement: 6000 kcal – Operating temperature range: 5–10 °C

  • Machine Dimensions:

    • Height: 2000 mm

    • Length: 4700 mm

    • Width: 2300 mm

  • Total Weight: 8700 kg

This system, which stands out with its fully automatic and user-friendly design for facilities producing high volume PET bottles, reduces labor needs with its automatic preform feeding and robot-assisted systems, while providing both speed and quality in the production process.

Offered with the assurance of Mucitler Makina, this system is a powerful and economical solution for businesses seeking maximum performance in large water bottle production.
