2 Ton Hydraulic Cargo Platform

Brand Expert Lifting
Model Type

EYP-2

Category:
Description

Expert Lifting EYP-2 2 Ton (1500×2000 mm) Hydraulic Cargo Platform

  • Production compliant with cargo platform standards

  • Safe and smooth cargo lifting and lowering

  • 24/7 technical support and after-sales service

  • High security certified steel rope and/or chain gear system

  • Optional PLC control unit with 'soft start -soft stop' operating system

  • Cargo platforms are widely used to safely and smoothly transport palletized cargoes, crates, etc. between floors in workplaces such as factories, warehouses, workshops, working on the principle of hydraulic lifting that moves on guide rails.

  • Designed to be used comfortably both indoors and outdoors

  • With a highly durable steel construction, it is resistant to harsh conditions and has an ergonomic and stylish design.

  • Hydraulic cargo platforms provide fast, efficient, comfortable, and safe transportation to multiple floors, mezzanines, basements, garage, or any desired floors

  • In places where pits cannot be dug, loading and unloading can be easily done with the internal ramp.

Expert Lifting EYP-2 Technical Specifications





MODEL



MAXIMUM LIFTING CAPACITY



PLATFORM DIMENSIONS

(MM)



LIFTING HEIGHT

(MM)



PIT DIMENSIONS

(MM)



MOTOR

POWER

(KW)



ELECTRIC

SUPPLY

ACV



EYP-1



< 1000 KG



1300 X 1000



0-8000



1350 X 1150



2.2



220-380



EYP-2



 < 2000 KG



1500 X 2000



0-6000



1670 X 2500



4



380



    EYP-5



   < 5000 KG



2500 X 4000



   0-5000



2500 X 4600



    7.5



    380
