20-50 Bottle Capsule Counting Machine

Brand Meditek Makina
Model Type

M-KS001

Description

Meditek

20-50 Bottle Capsule Counting Machine

  • Wide applicability: Used for tablets (including abnormal tablets), capsules, gels (including abnormal gels, transparent gels, and opaque gels), pills, and most solid granules.

  • Anti-dust: Using our original high anti-dust sensor technology, the machine operates accurately with good stability under heavy dust conditions.

  • Product Safety: Can quickly bottle small mouth bottles with a specially designed hopper mouth to prevent material jamming. (optional)

  • Detection function: Automatically removes bottles with filling errors and broken tablets of a certain size.

  • Self-diagnoses errors and stops operation (counting) by giving an alarm in case of errors, completing the count after error compensation.

  • Produced in accordance with GMP and GEP standards and in compliance with the documents required by the Ministry of Health (IQ, OQ, PQ, DQ).

Meditek Capsule Counting Machine Technical Specifications:





Capacity

20 – 50 bottle capacity



Filling Accuracy

± % 2



Speed

Adjustable (Digital Screen Controlled)



Sizing

(multiple block chassis cabinet combination)

Hardware And Parts

EQUIPMENT DESCRIPTION

1

Machine Model

Automatic Drug Filling Line

2

Machine Type

Tablet Counting Machine

3

Line Arrangement

Linear Line

4

Filling Type

Granule (tablet)

5

Capping System

Automatic Cap Feeding and Capping

6

Stopper System

Automatic Feeding and Stopper Insertion as an Option According to the Product

7

Input and Output Unit

Conveyor Input and Output

FEATURES

1

Electric Supply

380 V

2

Power Consumption

1.5 Kw

3

Pneumatic Connection

6-8 Bar

4

Air Consumption

750 L/min
