200-300 Tons / Hour (In Stock) Tertiary Impact Crusher

Fabo Machinery TK-130 200-300 Tons / Hour (In Stock) Tertiary Impact Crusher

*All our products are carefully manufactured and are covered by a 1-year warranty!
*Installation and Operator Training are FREE

TK Series Tertiary crushers provide solutions for materials of medium hardness and fall into the category of impact crushers with their working principle. Generally, these types of crushers are used as the third crusher in the system, which are the best machines to meet the industry’s 0-5 mm sand requirement. Tertiary Impact Crushers are also known as sand machines.
The sand machine provides the production of fine and cubic products with its high-speed rotor. It produces products according to the gradation required by concrete plants and asphalt facilities based on sand size distribution. One of the most important features of our TK Series Tertiary crushers is that it can operate the rotor in both directions, allowing operators to change the working direction of the rotor when parts wear out on one side of the crusher. This method reduces inventory costs for customers by decreasing maintenance requirements and part costs. It can be opened for easy maintenance and spare part replacement thanks to two hydraulic pistons on both sides.

TECHNICAL SPECIFICATIONS

• Model: FABO TK-130
• Type: Tertiary Impact Crusher
• Capacity: 200-300 tons/hour
• Rotor Size: 1200 x 1300 mm
• Maximum Feed: 120 mm
• Motor: Heavy-duty GAMAK, 250-315 kW Bearings: Heavy-duty SKF-FAG
• Speed: 750 rpm
• Weight: 13850 kg
• Size: 2900 x 2150 x 2685 mm
• Includes chassis, motor, and safety guards.

GENERAL FEATURES

• High capacity and efficiency
• Perfect grinding thanks to high-speed rotor
• Longer service life due to dual-direction rotor
• Wear surfaces are protected with solid fill electrode welding
• Crushers and crushing plates are made of high manganese and chromium steel castings.
• The internal surfaces of the crusher are lined with wear-resistant liner plates.
• Easy maintenance thanks to hydraulic adjustment system

FOR DETAILED INFORMATION, PLEASE CALL US!!!
