200cc – 5 Litre 500 Bottle/Hour PET Jar Blowing Machine

200cc – 5 Litre 500 Bottle/Hour PET Jar Blowing Machine

Inventors Machine ESHF2-HCV-5LT-WN – 2 Station Semi-Automatic PET Jar & Blowing Machine (200 cc – 5 Litre)

ESHF2-HCV-5LT-WN is a semi-automatic blowing machine with 2 stations developed by Inventors Machine for the production of PET jars and bottles with volumes ranging from 200 cc to 5 litres. This model, with its manual preform feeding design, offers a user-friendly solution for medium-scale production facilities.

The machine operates with a production capacity of 500 bottles per hour and features a specially adjustable 6-row lamp system for short preforms. Optionally, it can be adapted to higher heating needs with 8 or 10 rows of lamps.

Technical Specifications:

• Number of Stations: 2 stations

• Preform Feeding: Manual feeding

• Capacity: 500 bottles/hour

• Bottle Dimensions: 300 mm diameter x 350 mm height

• Bottle Volume: between 200 cc – 5 litres

• Lamp Heating Rows:

  • Standard: 6 rows (adjustable for short preforms)

  • Optional: 8 or 10 rows

• Motor Powers:

  • 5 kW Mold Closing

  • 0.75 kW Oven Rotation

• Oven Heating Capacity:

  • 6 rows: 36 kW

  • 8 rows: 96 kW

  • 10 rows: 120 kW

• Cooling Requirement: 5000 kcal – Recommended temperature: 5–10 °C

• Machine Dimensions (oven and blowing combined):

  • Height: 1800 mm

  • Length: 2700 mm

  • Width: 2000 mm

• Total Weight: 1300 kg

ESHF2-HCV-5LT-WN is both a cost-effective and compact production solution for businesses producing PET jars and large volume bottles. The semi-automatic system provides high control with low labor. Thanks to its modular oven structure, it can be customized according to your production needs.

With the assurance of Inventors Machine, this model stands out with its robust structure, flexible production capability, and energy efficiency.
