200×2100 mm Cylinder Bending Machine

MAC BENDING SBM 200X2100 HYDRAULIC CYLINDER BENDING MACHINE

MAC BENDING SBM 200X2100 HYDRAULIC CYLINDER BENDING MACHINE General Features:

– Central Elevator

– Hydraulic Side Supports

– 10” multifunctional touch screen

– PLC controlled manual, semi-automatic and automatic bending (playback)

– 3 speed feature

– Bearing support system

– Body and components made of St-52 quality steel

– Lower top pressure adjustment

– Hydraulic openable – closable upper shaft cover and movable upper shaft

– Automatic balance system with one button

– Conical sheet bending system

– Conical bending auxiliary apparatus

– Separate hydraulic motor and planetary reducer drive system for upper and lower rolls

– Sliding system

– Hidden against shocks, encoder system that precisely measures the rotational movement

– Current protection system against overloads

– Continuity button that ensures the continuous rotation of the rollers

– Induction hardened and polished shafts (Ck45)

– Separate movable control panel with three positions

– Remote access via the internet

– Formula page calculating radius, spring and depth

– Audible-light buzzer warning system

– Rope switch for safety around the machine

– Warning page showing maintenance time

– Alarm page showing warnings in the machine

– Production in accordance with CE standards

– Transparent protective cover for the control panel

– Ultrasonic sensor

MAC BENDING SBM 200X2100 HYDRAULIC CYLINDER BENDING MACHINE Description:

Bend your sheet materials perfectly with the precise and efficient 4 Roll Hydraulic Cylinder Bending Machine. Increase your business productivity with CNC and NC control features, robust structure, durability, and flexible features. We are here with expert support and after-sales services.

Technical Specifications  MAC BENDING SBM 200X2100 HYDRAULIC CYLINDER BENDING MACHINE:

Working Length 2000

Maximum Thickness 10

Pre-Bending 8

Upper/Lower Shaft Ø200

Side Roll Ø180

Motor Power 7.5 kW

Dimensions L/W/H (mm) [ PHONE HIDDEN ]

Weight 5660 kg
