2050X22mm – 3 Roll Hydraulic Cylinder Bending Machine

HSB 3R 20–300 Hydraulic 3 Roll Cylinder Machine (OEM)

⚙️ Standard Equipment

• Side rolls are hydraulically movable up and down with an orbital piston

• Overload protection system

• All rolls are driven by a hydraulic motor and planetary reducer

• Hydraulically opening head allows for easy removal of the bent piece

• Movable control panel for easy and ergonomic use

• Position of the lower rolls can be easily read with two digital displays

• Welded steel construction body

• SAE 1050 (CK45) induction hardened, hot rolled steel shafts

• Bearing conical bending system

• Hydraulic balancing system for parallel movement of the shafts

• Extended shaft ends for attaching profile and pipe bending rolls

🔩 Optional Equipment

• For support in large diameter bending, overhead crane (elevator)

• For support in large diameter bending, hydraulic side supports

• For special jobs, ground and polished rolls

• Rolls for bending profiles

• Infinitely variable hydraulic speed adjustment

• For parallel movement of the shafts, electronic balancing system

📊 Technical Specifications

• Bending Length: 2050 mm

• Pre-Bending: 16 / 20 mm

• Bending: 20 / 22 mm

• Upper & Lower Roll Diameter: Ø300 mm

• Side Roll Diameter: Ø280 mm

• Motor Power: 11 kW

• Bending Speed: 5 m/min

• Machine Length: 4100 mm

• Machine Width: 1500 mm

• Machine Height: 1550 mm

• Machine Weight: 7400 kg

🏭 OEM Production Note

This machine is manufactured in Turkey under OEM production.
Supply, configuration, and commercial management are conducted by CRONOSSTECH.
