240 Kg Monorail Facade Cleaning System
| Brand | Bmunit |
|---|---|
| Model Type |
Sis 75 |
240 Kg Monorail Facade Cleaning System
Aluminum rail, (monorail) with horizontal and vertical movable facade cleaning system installed with special connection feet to the building facade. Single or double person platform suitable for request and building structure can be used. The platform can move manually or automatically thanks to special movement trolleys. Aluminum monorail production and installation is made according to the shape and length of the building facade.
Monorail carrier arms can be mounted from the front facade of the building, inside the parapet, behind the parapet to the terrace or under the eaves. Rails can be in natural aluminum color or painted as desired. All movements can be controlled from the work platform. Vertical movement is achieved by the motorized climbing mechanism on the work platform.
The 2 polyurethane facade wheels on the platform do not damage the glass surfaces. Safety measures such as dual safety rope, safety lock system, rope tension control provide a safe working environment. Operator errors are prevented by the overload detection system, lower impact prevention bar, lower limit switch, and upper limit switch. Production and installation are carried out in accordance with EN 1808 standards.
General Introduction
In the monorail system, the rail and console are placed inside or outside the wall panel in the most suitable way according to the static and dynamic load calculated according to the architectural structure of the building.
-
Rails can be passed around the building to clean every point thoroughly.
-
The railing is made of special aluminum material to give your building a beautiful appearance.
-
It does not cover space on the terrace, so the structure can be largely utilized from the terrace.
-
After cleaning, you can park the system in the most appropriate position due to its compact structure.
-
By collaborating with two people on the platform, it provides cleaning opportunities.
Application Standards
-
The facade cleaning system is produced in accordance with EU directives and our company has an ISO 9001 quality certificate.
-
Our production is carried out in accordance with the following standards.
-
EN 1808 standard
-
98/37 EC Machinery Safety Directive
-
2006/95 / EC Low Voltage Standard
Features
-
Connection Feet and Rail: Aluminum rail (monorail) with special connection feet for mounting on the building facade, allowing horizontal and vertical movement.
-
Platform Options: Single or double person platform suitable for request and building structure can be used.
-
Movement Trolleys: The platform can move manually or automatically thanks to special movement trolleys.
-
Production and Installation: Aluminum monorail production and installation are carried out according to the shape and length of the building facade.
Installation and Rail Options
-
Monorail Carrier Arms: Can be mounted from the front facade of the building, inside the parapet, behind the parapet to the terrace or under the eaves.
-
Rail Color Options: Rails can be in natural aluminum color or painted as desired.
Control and Movement
-
Control: All movements can be controlled from the work platform.
-
Vertical Movement: Vertical movement is achieved by the motorized climbing mechanism on the work platform.
-
Facade Wheels: The 2 polyurethane facade wheels on the platform do not damage the glass surfaces.
Safety Measures
-
Dual Safety Rope: Safety lock system and rope tension control.
-
Overload Detection System: Prevents operator errors with lower impact prevention bar, lower limit switch, and upper limit switch.
-
Standards: Production and installation are carried out in accordance with EN 1808 standards.
Technical Specifications:
| Specs | Value |
|---|---|
| Used Systems | SIS 50 / SIS 75 / SIS 85 / SIS 85-20 / SIS 90 / SIS 95 / SIS 100 / SIS 105 |
| Power | 3 kW |
| Rope | 4 pcs 8 Mm Steel Rope |
| Voltage | 380 V |
| Control | Cable |
| Vertical Speed | 7 Mt / Min – 2 pcs 2.2 kW |
| Horizontal Movement | Manually / Motorized |
| Forward Opening Distance | 1 meter opening distance. |
| Platform Weight | 300 Kg (Can vary according to building height.) |
| Operating Capacity | 240 Kg |
