254×1270 mm Moulder Milling Machine

JETCO JBE 3Q MOLDING MILLING MACHINE

Jetco Jbe 3Q Molder Milling Cutter Capacity:

X axis alignment is motorized, Table size is 254×1270 mm, Table

Jetco Jbe 3Q Moulder Milling Cutter Accessories:

X

Specifications   Unit JBE-3Q

Table size mm 254 x 1270

T. channel mm    mm      16 x 3 x 63

X-axis travel of table mm      825 (manual: 914)

Y axis movement of the table    mm      400

Z axis movement of the table mm      406

Head up/down movement          mm      610

Spindle quill travel               mm      127

Pinole diameter         mm      85.72

Engine HP         3

Spindle taper                       ISO40

Speed ​​change 16-speed speed

Spindle speed       rpm  80-5440

Head rotation angle                  Right/Left 90° – Front/Rear 45°

Net weight       kg          1200
