3-Piece Cylinder Sheet Bending Machine

Brand

SBFM

Model Type

3R SBS Serisi

Biko Export 3R SBS

3-Piece Cylinder Sheet Bending Machine

It is used in the industry to bend thin or thick sheet plates at the desired angle, into full circles, half circles, and conical shapes.

*Sheet bending capacity is given for steel with a yield strength of 24 kg/mm2.
*Dimensions are approximate values. SBFM can change the dimensions without notice.

The material is aligned between three cylinders. The pre-bending process is performed. After this stage, the bending process is carried out at the desired diameter.

Biko Export 3R SBS Technical Specifications:

Model	Bending Length	Without Pre-Bending	With Pre-Bending	Min. Bending Diameter	Upper Roll Diameter	Side Roll Diameters	Motor Power	Machine Dimensions (H-W-L)	Weight
Model	mm	mm	mm	ø mm	ø mm	ø mm	kW	mm	kg
3R SBS 2006	2050	6	4	Upper roll x2	180	160	3.3	4000x1000x1000	2100
3R SBS 2008	2050	8	6		190	180	5.5	4000X1000X1100	3000
3R SBS 2010	2050	10	8		210	190	7.5	4000X1100X1100	4000
3R SBS 2013	2050	13	10		240	220	11	4200X1300X1300	4700
3R SBS 2016	2050	16	13	Upper roll x3	280	250	11	4500X1500X1500	5500
3R SBS 2020	2050	20	16		300	270	15	4500X1600X1600	7000
3RH SBS 2025	2050	25	20		330	300	19	4500X2400X1750	8500
3RH SBS 2030	2050	30	25		360	330	19	3500X2500X2000	10000
3RH SBS 2035	2050	35	28		380	350	26	5000x3250x2700	15000
3RH SBS 2040	2050	40	30		390	360	26	5000x3300x2700	17000
3RH SBS 2045	2050	45	35		420	390	30	5000x3500x2750	19500

3R SBS 2506	2550	6	4	Upper roll x2	190	180	5.5	4500X1000X1100	3400
3R SBS 2508	2550	8	6		210	190	7.5	4500X1100X1100	4250
3R SBS 2510	2550	10	8		240	220	11	4700X1300X1300	4700
3R SBS 2513	2550	13	10		280	250	11	5000X1500X1500	6000
3R SBS 2516	2550	16	13	Upper roll x3	300	270	15	5000X1600X1600	8000
3R SBS 2520	2550	20	16		330	300	19	5000X1800X1800	10000
3RH SBS 2525	2550	25	20		360	330	19	5500x3200x2700	11500
3RH SBS 2530	2550	30	25		380	350	26	5500x3250x2700	14500
3RH SBS 2535	2550	35	28		390	360	26	5500x3300x2700	15500
3RH SBS 2540	2550	40	30	Upper roll x4	420	390	30	5500x3500x2750	17000
3RH SBS 2545	2550	45	35	Upper roll x4	450	420	37	6000x3750x2850	25000

3R SBS 3006	3100	6	4	Upper roll x2	210	190	7.5	5000X1100X1100	4400
3R SBS 3008	3100	8	6		240	220	11	5200X1300X1300	5200
3R SBS 3010	3100	10	8		280	250	11	5500X1500X1500	7200
3R SBS 3013	3100	13	10		300	270	15	5500X1600X1600	8500
3R SBS 3016	3100	16	13	Upper roll x3	330	300	19	5500X1800X1800	11000
3R SBS 3020	3100	20	16		360	330	19	6000x2000x2000	13500
3RH SBS 3025	3100	25	20		380	350	26	6000x3250x2700	16500
3RH SBS 3030	3100	30	25		390	360	26	6000x3300x2700	17500
3RH SBS 3035	3100	35	28	Upper roll x4	420	390	30	6000x3500x2750	20000
3RH SBS 3040	3100	40	30	Upper roll x4	450	420	37	6500x3750x2850	28000

3R SBS 4006	4100	6	4	Upper roll x2	280	250	19	6500X1500X1500	8500
3R SBS 4008	4100	8	6		300	270	19	6500X1600X1600	9500
3R SBS 4010	4100	10	8		330	300	26	6500X1800X1800	12500
3R SBS 4013	4100	13	10	Upper roll x3	360	330	26	7000x2000x2000	15000
3R SBS 4016	4100	16	13		380	350	30	7000x2200x2200	18000
3R SBS 4020	4100	20	16		390	360	30	7000x2400x2400	19500
3RH SBS 4025	4100	25	20	Upper roll x4	420	390	37	7000x3500x2750	22000
3RH SBS 4030	4100	30	25	Upper roll x4	450	420	37	7500x3750x2850	30000

Brand	SBFM
Model Type	3R SBS Serisi

Category: Sheet Processing Machines
