30.00 M (200 Kg) Spider Articulated Platform

Easy Lift R300 is a spider articulated platform that can reach heights of up to 30 meters. This platform offers a wide working area with a horizontal reach of 14.50 meters and a 360° turning angle.

With a maximum lifting capacity of 200 kg, the R300 can safely carry various equipment.

Since the platform’s basket dimensions are 2.0 x 0.8 meters, users can have a wide working area and easily place the necessary equipment.

Additionally, the weight of the platform is 6000 kg, which provides stability and safety.

Easy Lift R300 is equipped with a powerful Hatz diesel engine and a high-capacity lithium battery.

There is also an electric motor option for environmentally friendly operation.

With these features, the Ertek Easy Lift R300 offers a reliable and efficient solution for construction, maintenance, cleaning, and similar industrial applications.

It facilitates users’ access to high places while also enhancing safety and work efficiency.

Max Height: 30.00 m

Horizontal Reach Distance: 14.50 m

Turning Angle: 360°

Max Lifting Capacity: 200 kg

Weight: 6000 Kg

Basket Dimensions: 2.0 x 0.8 m

Diesel Engine: Hatz 25.7 kW

Battery: Lithium 200Ah/h

Electric Motor: 3.0 kw-230V-50Hz
