300 mm Fully Automatic Mitre Band Saw

OZCO TA300M FULLY AUTOMATIC MITRE BAND SAW

OZCO TA300M FULLY AUTOMATIC MITRE BAND SAW Description:

Infinite steps in the range of 20-100 m/min with inverter speed adjustment/Vario system, Digital speed indicator, Hydraulic/Automatic material clamping, Hydraulic/Automatic head movement, Manual material feeding, Ergonomic control panel for ease of use, Specially designed cast pulleys, Hydro-mechanical blade tensioning, Domestic production powerful motor, Domestic production specially designed reducer, Material feeding system reinforced with specially designed double bearing system and long-lasting feeding balls, Adjustable vice pressure system for clamping pressure adjustment suitable for material type, Band saw system with double bearing pressing that increases cutting precision, High quality cooling motor of Italian origin, Chip brush, Schneider electrical system, Compliant with CE standards, Made in TURKEY

OZCO TA300M FULLY AUTOMATIC MITRE BAND SAW Shipment Scope:

5 Roller material support, Bi-metal saw blade mounted on the machine

Technical Specifications OZCO TA300M FULLY AUTOMATIC MITRE BAND SAW

Motor Power     1.5 kW, 380 V

Cutting Capacity 0° Round: 300 mm; Square: 300×300 mm; Rectangular: 240×330 mm

Cutting Capacity 45°             Round: 200 mm; Square: 180×180 mm; Rectangular: 160×270 mm

Cutting Angle     0°-45°

Speed        20-100 rev/min

Step            Inverter / Infinite

Material Feeding Height             760 mm

Vice Opening Range         0-335 mm

Vice Height  190 mm

Driving Motor Power   0.37 kW

Hydraulic Motor Power 0.18 Kw

Cooling Motor Power              0.12 W

Machine Dimensions (LxWxH)      2260x1260x1430 mm

Weight 800 Kg
