3000 Ton Servo Plastic Injection Machine
| Brand | Ce-Ba/Haitai |
|---|---|
| Model Type |
HTW-3000 |
Ce-Ba/Haitai HTW-3000
3000 Ton Servo Plastic Injection Machine
General Features
The energy-saving injection molding machine is equipped with a high-performance servo motor control system.
This study aims to design servo motor-driven injection machines.
With this study, the technological gains, features, speed, precision, energy efficiency, and quality of the next-generation plastic injection machine designed using servo motors have been compared to traditional A/C motor machines.
Ce-Ba/Haitai HTW-3000 Technical Specifications
.png)
|
MODEL CODE |
|
HTW3000 |
|||
|
INJECTION UNIT |
INJECTION UNIT |
Unit |
|
||
|
SCREW TYPE |
Screw Type |
|
A |
B |
C |
|
SCREW DIAMETER |
Screw diameter |
mm |
180 |
210 |
220 |
|
SCREW L/D RATIO |
Screw L/D ratio |
L/D |
24 |
24 |
22.9 |
|
SHOT VOLUME |
Shot volume(therretical) |
cm3 |
29390 |
40003 |
43904 |
|
INJECTION WEIGHT |
Injection weight(ps) |
g |
26745 |
36402 |
39953 |
|
INJECTION RATE |
Injection rate |
Mm/s |
1468 |
2000 |
2200 |
|
INJECTION PRESSURE |
Injection pressure |
MPa |
210 |
155 |
141 |
|
SCREW SPEED |
Screw speed |
rpm |
50 |
||
|
CLAMPING UNIT |
CLAMPING UNIT |
|
|
||
|
CLAMPING FORCE |
Clamping force |
KN |
30000 |
||
|
OPEN STROKE |
Open stroke |
mm |
2000 |
||
|
SPACE BETWEEN TIE BARS |
Space between tie bars(W×H) |
mm |
1900X1750 |
||
|
MAX. MOULD HEIGHT |
Max.Mould height |
mm |
1900 |
||
|
MIN. MOULD HEIGHT |
Min.Mould height |
mm |
1000 |
||
|
EJECTOR STROKE |
Ejector stroke |
mm |
450 |
||
|
EJECTOR FORCE |
Ejector force |
KN |
565 |
||
|
OTHER PARAMETERS |
Others |
|
|
||
|
SYSTEM PRESSURE |
[ URL HIDDEN ] pressure |
MPa |
16 |
||
|
SERVO MOTOR POWER KW |
Pump motor power |
KW |
55+55+55+55 |
||
|
HEATING POWER KW |
Heating power |
KW |
177 |
||
|
MACHINE DIMENSIONS |
Machine dimension(L×W×H) |
m |
22.0X5.50X5.0 |
||
|
OIL TANK CAPACITY |
Oiltank cubage |
L |
4500 |
||
|
MACHINE WEIGHT |
Machine weight |
t |
200 |
||
