300×1370 mm Universal Mold Maker Milling Machine
| Brand | Koyuncu |
|---|---|
| Model Type |
YSM 26 SHB |
Description
Koyuncu YSM 26 SHB
300×1370 mm Table Range Universal Mold Maker Milling Machine
Koyuncu YSM 26 SHB Technical Specifications
|
TABLE DIMENSION |
300 x 1370 mm |
|
T CHANNEL DIMENSION |
16 x 3 x 61 mm |
|
X – Y – Z AXIS MOVEMENTS |
1000 x 400 x 480 mm |
|
SPINDLE CONE |
ISO 40 |
|
QUILL DIAMETER |
105 mm |
|
QUILL MOVEMENT |
140 mm |
|
SPINDLE RPM ( VERTICAL ) |
58 – 5560 rpm |
|
SPINDLE RPM ( HORIZONTAL ) |
75 – 1450 rpm |
|
MOTOR POWER |
22kg |
|
WEIGHT |
|
Koyuncu YSM 26 SHB General Features
-
X – Y Axes SERVO feed motors
-
Z Axis automatic motor up and down
-
Hardened Table
-
Turcite – B coated X-Y slides
-
Emergency stop button
-
X – Y box slide
-
X – Y axes ball screws
Koyuncu YSM 26 SHB Standard Accessories
-
COLLET SET
-
VISE
-
CLAMPING SET
