4.35 M Speed ??Boat / Northstar Ns 435 Tj
| Brand | Northstar |
|---|---|
| Model Type |
NS 435 TJ |
Description
The ultra sports Jokey console TJ series is designed for those who expect a lot from their small-sized boats. The TJ series, featuring unique, ergonomic jokey consoles, incorporates all the unique quality features of Northstar with perfect control of use. The GRP parts of the TJ series are produced with vacuum infusion and RTM technologies, just like in other Northstars, providing perfect durability and lightness.
The integrated bow locker, 4 lifting points, deck drainage system, wide diameter Hypalon tubes, and sports jokey console make the TJ series a preferred choice for sports tenders, water sports businesses, and yacht clubs.
| TECHNICAL SPECIFICATIONS | 335 TJ | 370 TJ | 400 TJ | 435 TJ | 480 TJ | |||||
| Full Length | 3.35 m | 3.72 m | 4.00 m | 4.35 m | 4.80 m | |||||
| Full Width | 1.48 m | 1.64 m | 1.70 m | 2.00 m | 2.02 m | |||||
| Inner Length | 2.45 m | 2.80 m | 3.10 m | 3.32 m | 3.70 m | |||||
| Inner Width | 0.72 m | 0.76 m | 0.79 m | 1.00 m | 1.00 m | |||||
| Tube Diameter | 0.42 m | 0.42 m | 0.48 m | 0.48 m | 0.50 m | |||||
| Air Chambers | 3 | 3 | 3 | 4 | 4 | |||||
| Empty Weight | 110 kg | 128 kg | 135 kg | 155 kg | 175 kg | |||||
| Maximum Carrying Capacity | 4 people / 340 kg | 5 people / 425 kg | 5 people / 425 kg | 7 people / 630 kg | 8 people / 720 kg | |||||
| Maximum Engine Power | 14.7 kW (20 HP) | 22 kW (30 HP) | 29.4 kW (40 HP) | 36.8 kW (50 HP) | 64 kW (87 HP) | |||||
| Engine Shaft Oil | S | S | L | L | L | |||||
| Fuel Tank Capacity | – | – | – | – | – | |||||
| Water Tank Capacity | – | – | – | – | – | |||||
| Recommended Tube Pressure | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | |||||
| CE Design Category | C | C | C | C | C |
