4.5 Meter Light Type Scissor Lift Personnel Platform
| Brand | Els Lift |
|---|---|
| Model Type |
EL 4.5 Junior |
4.5 Meter Light Type Scissor Lift Personnel Platform
Els Lift EL 4.5 Junior
Els Lift EL 4.5 Junior SP Technical Specifications
|
Maximum Lifting Capacity |
240kg |
|---|---|
|
Climbing Slope |
25% |
|
Platform Take-off / Landing Time |
14 x 14 sec |
|
Wheel Radius |
0.10m |
|
Hydraulic Tank Capacity |
2.5L |
|
Hydraulic Unit |
12V / 1kW / 1.0cc |
|
Battery |
12V / 105A/h |
|
Battery Charger |
13.8V / 17.4A |
|
Total Weight |
365kg |
|
emergency stop button |
|---|
|
Charging protection system |
|
cylinder retaining valve |
|
Maintenance safety device |
|
Non-marking tires |
|
tilt sensor |
|
emergency download system |
|
load detection sensor |
|
Ability to be transported by forklift and crane |
|
CE-EN280 certification |
|
Audible warning during landing |
|
Maximum Working Height |
4.5m |
|---|---|
|
Maximum Platform Height |
2.5m |
|
Closed Height (Platform) |
0.67m |
|
Closed Height (Guardrail) |
1.78m |
|
Chassis Ground Height |
0.07m |
|
Chassis Width |
0.75m |
|
Axle Center Range |
1.00m |
|
Length |
1.17m |
|
Length (With Step) |
1.20m |
|
Platform Width |
0.59m |
|
Platform Length |
1.07m |
