4.8 Meter Elevator 2.0 Ton Lithium 3 Wheel Electric Forklift
| Model Type |
CPD15TVL |
|---|
4.8 Meter Elevator 2.0 Ton Lithium 3 Wheel Electric Forklift
Litef Forklift’s Lithium Electric, 3 Wheel (Twin), Dual Drive Counterbalanced Forklift Solution – 1.5-1.8 and 2.0 tons
Designed with the advantages of fully lithium-ion technology in mind, the TVL series has a small turning radius for narrow aisle warehouse applications and provides optimum operator comfort and high load stability. The TVL series, powered by an 80-volt, 2*5 kW front-wheel drive motor, significantly increases your productivity with 6 hours of operation per charge.
The TVL series can be used for almost any work application. With a small turning radius of 1450 mm for CPD15TVL, 1550 mm for CPD18TVL, and 1585 mm for CPD20TVL, it meets the requirements for indoor storage transportation, especially for narrow aisle applications. Additionally, thanks to the powerful 80V Lithium Battery performance, it offers good performance when loading and unloading on truck loading ramps or side-loading vans. The lithium-ion powered TVL series makes it an excellent forklift for product handling by providing the opportunity for short charging during the day.
Included;
- Capacity; [ PHONE HIDDEN ] KG lifting and transporting
- Lithium Ion Battery
- 80V/150 AH – 80V/205 AH Lithium Battery
- 80V/60A – 80V/35A Fast Charger – full battery charge in 2 hours
- 4800 mm and 6000 mm Triplex Lift – Wide Operator Visibility
- Cascade Integral Side Shift (left-right shifting)
- 1220 mm Forklift Fork
- Suspended, Seat Belted, Switchable, Comfortable Operator Seat
- Front LED Lights and Warning (Top) Light
- Solid Tires
- Telematics System (Real-time value, location, parameters, error, fault, charge status tracking)
- Connection with Bloutouth (Ability to see the forklift’s location, charge level, etc. in real-time from the Mobile Application)
-
Drive Motor Power 2×5 KW / Hydraulic Motor Power 11 KW
- No battery maintenance / No carbon footprint / Zero emissions, environmentally friendly
- interlock and liftlock safety systems
-
2 Year 2000 Hour Forklift Warranty (WHICHEVER EXPIRES FIRST) / 5 years / 5000 hours battery warranty (WHICHEVER EXPIRES FIRST)
-
Up to 92% fuel savings compared to diesel forklifts
We imported the Lithium Battery CPD15/18/20TVL Model Forklift to solve the following stacking problems.
- Powerful Dual AC Motor mechanism driven Lithium Battery counterbalanced twin wheel forklift.
- We imported TVL series forklifts for power, agility, and higher vertical stacking requirements in tight spaces.
- Provides uninterrupted work power productivity with the ability to use for 6 hours on a single charge, full charge in 2 hours, and interim charging options for multi-shift operations.
- Eco-friendly Energy, thanks to the 80V/205 or 80V/105 Ah Lithium Battery, is useful for multiple shifts.
- Thanks to the integrated fast charger, it offers opportunity charging, meeting the needs for multi-shift operations.
- Being chargeable with single-phase city electricity, TVL series forklifts provide solutions for a wide range of companies from large-scale logistics firms to small-scale firms operating within urban settlements.
- TVL Series Lithium battery Forklifts are equipped with EP’s in-house preventive service application for direct access to parameter monitoring and changes via Bluetooth and real-time diagnostics to enhance maintenance efficiency and extend the forklift’s lifespan.
- TVL series Lithium battery 3 Wheel Forklifts are designed for businesses that want to own a quality, practical forklift. Additionally, thanks to the frequently rechargeable lithium battery, it saves from the cost of having a separate machine for each shift in large factories and logistics companies with multi-shift applications.
- CPD15TVL, with a small turning radius of 1450 mm, CPD18TVL 1550 mm, and CPD20TVL 1585 mm, is the most ideal with a 3.5 meter shelf spacing.
- TVL series guarantees high maintenance efficiency with the EP preventive service application that allows operators to connect the forklift via Bluetooth for parameter changes and monitoring, as well as diagnostic trouble code reading without a handheld computer.
-
- TVL Series offers a wide working area with its simplified panel, adjustable steering wheel, and comfortable pedal. All designed with ergonomic considerations for working comfort.
-
TVL series is the most comfortable with a 394 mm operator foot working area.
- CPD15TVL Forks length to face: 1813 mm(L2) total width: 1070 mm(b1/b2)
- CPD18TVL Forks length to face: 1913 mm(L2) total width: 1070 mm(b1/b2)
- CPD20TVL Forks length to face: 1950 mm(L2) total width: 1170 mm(b1/b2)
You can request the following features for TVL series 3 Wheel Lithium Battery forklifts.
- Forklift Fork Option; you can request forks in different sizes from 900 mm to 2400 mm.
- Lift Height; Up to 6 Meters from 3 meters
- Tire Type; Solid / Pneumatic / Non-marking Solid / Flexible Hole Solid
- Battery Capacity; 80V/150AH – 80V/205AH
-
Charger Options – External/Internal – Fast/Slow
-
Cabin/Heater and Canopy options are available.
