4.80 M Speed Boat / Northstar Ns 480 Tj
| Brand | Northstar |
|---|---|
| Model Type |
NS 480 TJ |
Description
The ultra-sports TJ series with Jockey console is designed for those who expect a lot from their small size boats. Offering excellent handling thanks to its unique, ergonomic jockey consoles, the TJ series incorporates all of Northstar’s unique quality features. GRP parts of the TJ series are produced with excellent strength and lightness using vacuum infusion and RTM technologies, as in other Northstars.
With its standard integrated bow locker, 4 lifting eyes, deck discharge system, large diameter Hypalon tubes and sports jockey console, the TJ series is the indispensable choice of both a sports tender, water sports establishments and sailing clubs.
| TECHNICAL SPECIFICATIONS | 335 TJ | 370 TJ | 400 TJ | 435 TJ | 480 TJ | |||||
| Full Size | 3.35m | 3.72m | 4.00m | 4.35m | 4.80m | |||||
| Full Width | 1.48m | 1.64m | 1.70m | 2.00m | 2.02m | |||||
| Inner Size | 2.45m | 2.80m | 3.10m | 3.32m | 3.70m | |||||
| Internal Width | 0.72m | 0.76m | 0.79m | 1.00m | 1.00m | |||||
| Tube Diameter | 0.42m | 0.42m | 0.48m | 0.48m | 0.50m | |||||
| Number of Air Chambers | 3 | 3 | 3 | 4 | 4 | |||||
| Curb Weight | 110kg | 128 kg | 135kg | 155kg | 175kg | |||||
| Maximum Carrying Capacity | 4 people / 340 kg | 5 people / 425 kg | 5 people / 425 kg | 7 people / 630 kg | 8 people / 720 kg | |||||
| Maximum Engine Power | 14.7 kW (20 HP) | 22 kW (30 HP) | 29.4 kW (40 HP) | 36.8 kW (50 HP) | 64 kW (87 HP) | |||||
| Motor Shaft Dimension | S. | S. | L. | L. | L. | |||||
| Fuel Tank Capacity | – | – | – | – | – | |||||
| Water Tank Capacity | – | – | – | – | – | |||||
| Recommended Tube Pressure | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | 0.22 Bar / 3.20 Psi | |||||
| CE Design Category | C. | C. | C. | C. | C. |
