42 Ton Electric Pallet Hydraulic Excavator
| Brand | Bonny |
|---|---|
| Model Type |
CJD420-9 |
42 Ton Electric Pallet Hydraulic Excavator
● It has an electric drive system that offers environmentally friendly advantages such as zero emissions, low noise levels, and low operating and maintenance costs. These features make it possible to meet increasingly stringent environmental scrutiny and assessment standards.
● By significantly reducing the need for manual labor, it helps save on labor costs, increases digging speed, and greatly enhances overall work efficiency.
● Since there is no gas source or flame in the electric system, the safety level during operation is very high.
● The hydraulic system specially developed for the machine allows precise and micrometric movements of the hydraulic scissors to be controlled. This ensures that cutting operations are carried out in a more stable, controlled, and reliable manner.
● The machine's specially designed undercarriage structure provides a strong and stable body structure. The body is produced in a nested and welded structure using high-strength steel.
● Depending on the operational need, a fixed elevated cabin or a hydraulically liftable cabin can be preferred. Both options provide the operator with a wide field of vision, enhancing safety and control at work.
|
Item |
Unit |
Value |
|---|---|---|
|
Machine weight |
t |
42 |
|
Electric motor rated power |
kW |
132 |
|
Electric motor rated speed |
rev/min |
1485 |
|
Maximum hydraulic flow |
L/min |
2 x 208 |
|
Maximum operating pressure |
MPa |
30 |
|
Control type |
— |
Hydraulic pilot control |
|
Hydraulic oil tank capacity |
L |
310 |
Working Equipment Data
|
Item |
Unit |
Value |
|---|---|---|
|
Boom length |
mm |
7100 |
|
Maximum cutting reach |
mm |
10,547 |
|
Maximum cutting height |
mm |
7404 |
|
Maximum cutting depth |
mm |
5727 |
|
Theoretical cutting force at maximum reach |
t |
410 |
