480 mm Mozaik Mermer Kesim Makinesi

480 mm Mosaic Marble Cutting Machine

The Marble Mosaic Cutting Machine is a model specially designed for precise and high-efficiency cutting operations. This machine, which achieves excellent results in cutting process with the use of 300-350 mm diameter saw, enables the production of marble mosaics in different sizes by working with a minimum of 2 and a maximum of 48 saws.

This model, which performs well even in intensive use thanks to the powerful 18.5 kW – 22 kW saw motor, can cut from a minimum of 10 mm to a maximum of 480 mm width. The machine can cut from a thickness of 10 mm up to 50 mm, standing out with its ability to process stones of different thicknesses.

The belt speed is adjustable between 0-5000 mm/min, and the machine has a stable and reliable working mechanism with a 0.55 kW belt motor and a 0.18 kW lifting/lowering motor. With its compact structure measuring 2000 mm in width, 2400 mm in length, and 1950 mm in height, it can be easily integrated into production lines.

Areas of Use

The Marble Mosaic Cutting Machine is widely used in many areas in the stone processing sector:

• Marble and Granite Processing: It is an ideal solution for the production of decorative mosaic stones.

• Interior Decoration: Used in the preparation of wall coverings, floor coverings, and special design marble panels.

• Bathroom and Kitchen Applications: Suitable for precise cutting of tiles, countertops, and mosaic details.

• Exterior Facade Cladding: Enables processing of natural stones in a thin and decorative manner.

• Landscape and Garden Design: Used in garden paths, pool edges, and decorative stone pavements.

Technical Specifications
