600 Ton H Type Double Connecting Rod Eccentric Press

H Type Eccentric Press – CEHP 600 Ton

Standard Features

• Steel construction body

• Pneumatic clutch – brake system

• T-channel additional slide plate

• 8 bearing slide

• Adjustable stroke in single crank arm

• Balancer piston on the slide

• Automatic fine lubrication system

• PLC control system

• Grand piano type control panel

• Touch screen LCD display

• Motor reverse movement

• Overload hydraulic safety

• Motorized slide adjustment mechanism

• Photoelectric protection curtain

• Gear set in closed oil tank

• Double-coil safety valve

• Compliance with CE standards

Optional Features

• Press feeding systems

• Waste material unloading systems

• Sliding safety cover in front of the table

• Mold with desired specifications

Technical Specifications

• Steel construction 8-slide monoblock body

• Vibration stress relief on the body and welded parts

• Effective area of moving table: 2200 × 1200 mm

• Effective area of fixed table: 2200 × 1200 mm

• Parallelism and perpendicularity tolerances comply with ISO and DIN standards

• Stroke distance: 200 mm (fixed)

• Table-slide distance (max.): 500 mm

• Slide adjustment (regulation): 120 mm

• Eccentric shafts: CK45

• Gears: Cast steel

• Motorized table-slide distance adjustment

• Approximate height of the press: 5200 mm

• Approximate width of the press: 3100 mm

• Approximate depth of the press: 3500 mm

• Distance of lower table from the ground: 900 mm

• Distance between walls: 2330 mm

• Side window size of the press can be adjusted as desired

• Flywheel bearing structure

• Slide guide: Bronze (Zr14)

• Connecting rods, intermediate and main bearings: Bronze (Zr14)

• Central automatic grease lubrication

• Double crank structure

• Pneumatic clutch and brake combination system (OMPI)

• 4 pieces of slide cushioning cylinders

• Approximate press weight: 77,000 kg

Automation and Electrical Information

• Main motor: 90 kW – IE3

• Touch panel and PLC: Delta

• PLC program for adapting mold to press

• Speed control device: Delta

• Operating speed: 25 – 45 strokes/min

• Mold recipe capacity: 100 pieces

• Switchgear components: Siemens & Schneider

• Grand piano type or wall type electrical panel

• Table-slide distance measurement can be monitored on the screen

Production Information

This machine is manufactured by CronossTech in Turkey.
