Ø 600mm Coiler
| Brand | Üstün Makine |
|---|---|
| Model Type |
UMS 600 |
Description
UMS 600 SERIES COILER
It is the machine located at the end of the coiler wire drawing machine, which allows the wire to be unloaded into the basket after the wire drawing process is completed..
The fixed block on which the wire is wound is specially coated with tungsten carbide against wear, and the pulley that guides the wire has also been coated with tungsten carbide after production.
|
UMS 600 SERIES COILER TECHNICAL SPECIFICATIONS |
|
|
BLOCK DIAMETER |
Ø600 mm. |
|
WIRE DIAMETER IT CAN UNLOAD |
Ø 1.50 – 5.00 mm. |
|
MACHINE SPEED |
It is synchronized with the wire drawing machine. |
|
SPEED ADJUSTMENT |
Controlled by AC drives with PLC unit |
|
MOTOR POWER |
30 kW 400 Volt AC
|
