65X3mm 5 Axis Mandrel Pipe Bending Machine Controlled by CNC

MB 65 CNC / 5-Axis Mandrel Tube Bending Machine

⚙️ Standard Features

• 1 set of bending mold according to customer's request

• 5-axis servo control system (Y – B – C – H – V)

• Servo motorized feeding axis

• Servo motorized rotation axis

• Servo motorized bending axis

• Servo motorized H and V axes

• Reducer-driven bending system ([ PHONE HIDDEN ])

• Mobile 21" color screen CNC control unit

• Bending with 3D simulation

• Automatic email sending of detailed work reports

• Daily / weekly / monthly total production tracking

• Calculating total material length to be used

• Estimating bending time

• Automatically converting X-Y-Z data to Y-B-C axes

• Remote support and service connection

• Portable foot pedal with emergency stop

• Manual and automatic bending modes

• Possibility of mandrel and mandrel-free bending

• Safety sheet with switch at the back of bending head

• Automatic mandrel lubrication system

• Hydraulic clamping system

• Hydraulic mandrel

• Hydraulic support

• Hydraulic linear slider system

• Hydraulic collets

• Hydraulic oil cooler

• Safety lock on electrical panel and key-lock panel

• Electrical panel cooler

• Overload protection system

🔩 Optional Features

• Spare bending mold set according to desired dimensions

• Servo bending ([ PHONE HIDDEN ])

• Safety mat (750 x 1000 mm)

• Safety mat (1000 x 1500 mm)

• Hydraulic oil heater

• Extra mandrel length (per meter)

• Spoon attachment and articulated mandrel

• Automatic mandrel lubrication system ([ PHONE HIDDEN ])

📊 Technical Specifications

• Max. Tube Diameter: Ø65 x 3 mm

• Max. Bending Radius: 300 mm

• Max. Bending Angle: 190°

• Number of Axes: 5 (Y – B – C – H – V)

• Feeding Axis (Y): Servo

• Rotation Axis (B): Servo

• Bending Axis (C): Servo

• Auxiliary Axes (H – V): Servo

• Hydraulic Working Pressure: 50 – 200 bar

• Max. Material Length: 3500 mm

• Rotation Accuracy: ±0.1°

• Control Unit: CNC – 21" color touchscreen

• Total Motor Power: 18.5 kW

• Machine Length: 6350 mm

• Machine Width: 1400 mm

• Machine Height: 1600 mm

• Machine Weight: ~3950 kg

🔒 OEM NOTE (common for all three)

These machines are manufactured under OEM production in Turkey,
supply, configuration, and commercial management are conducted by CRONOSSTECH.
