8-Bottle Cap Closing Machine

The automatic cap closing machine can be considered a definitive and complete solution for companies experiencing issues with cap placement and closing, due to its easy installation and simple integration into filling lines.

It automatically closes the caps of filled products coming from the filling group by either snapping, screwing, or applying them based on their characteristics. These machines, produced for the food, chemical, pharmaceutical, and similar industries, can also be manufactured in different systems according to capacity and cap models.

It has a durable chassis made entirely of 304 stainless steel.

Thanks to the double side belts, it is fixed with high precision during the cap closing process.

For packages of different heights, the automatic height adjustment can be set via the control panel.

For packages of different heights, easy usage is provided through the tilting lever and numbering systems, and this adjustment can be recorded via the touch control panel.

The machine’s speed settings and non-mechanical parts are PLC controlled, designed for easy disassembly and reassembly of variable parts.

The closing torque adjustment is made through the air inlet unit, allowing the closure of round, oval, square, and rectangular packages without the need for any part replacement.

The maintenance and cleaning of the machine can be easily performed.

Changes can be made to the machine’s dimensions according to demand.

The number of chambers specified in the machine’s technical details can vary according to bottle sizes and can be reduced or increased.

In standard feature machines, instead of processing one bottle at each cap closing and tightening station, two bottles can be processed at each station.

This process increases your capacity and shortens the lead time.

Meditek Bottle Cap Closing

Technical Specifications

The machine’s length is 1300 mm
The machine’s belt length is 3000 mm
The machine’s height is 1700 mm
The machine’s width is 1200 mm
The machine’s weight is 200 kg
Number of chambers: 8
Tightening apparatus: pliers system
Tightening torque system
Belt transitions: automatic

Motor: 0.37 KW (2 units)
Air Pressure: 8 Bar
Stainless Body Chassis: Guaranteed
Touch Screen: 7′ INCH
Electric Power: 0.75 KW 200 V
