Automatic Bottom Cutting Case Cutting Machine

Maximum cutting width:      240mm

Maximum cutting length:    2400mm

Minimum cutting length:       700mm

Maximum cutting height:    90’-80mm

Number of cutting units:           2

Cutting unit speed:            3800 rpm

Blade diameter:                        350mm

Number of drilling units:             2
Drilling unit speed:              3000 rpm

Drilling center spacing:     32mm  11 pieces

Cutting unit motors:    2×2.2 kw

Drilling unit motors:     2×1.1 kw

Total power:                        6.6

Voltage:                                  380v/50hz

Air pressure:                       6 bar

Length:                               3500mm

Width:                               1100mm

Height:                             1500mm

Weight:                                  900kg
