Electromechanical Desktop Compression Bending Tension Testing Device
| Brand | İbertest |
|---|
Ibertest Eurotest Series Electromechanical Desktop Testing Device
Customized and flexible design, single test area or double test area. Material testing machine developed to meet the highest standards in material testing according to international test standards: ISO 6892 tensile test, IS 1608, EN 10002-1, ASTM D695 compression test, bending test ASTM E290, testing according to nadcap.
Yield strength, % 0.2 upper limit and lower creep rupture load, ultimate elongation, etc. Maximum precision determination of key parameters in multiple material tests. Automatic calculation of anisotropy and sourness by combining axial and transverse strain gauge extensometers.
The available settings for Ibertest’s EUROTEST series are nearly limitless. The EUROTEST Electromechanical material testing device can comply with width, length, capacity (up to 1200kN), test standards, etc. as required.
A versatile framework with dozens of testing devices and interchangeable load cells, environmental chambers, furnaces, extensometry (manual and automatic) combined… offers wide possibilities for all types of static and fatigue testing at low frequencies for this testing machine.
|
EUROTEST 50 & 100 |
EUROTEST 200 |
EUROTEST 300 |
EUROTEST 400 |
EUROTEST 500 |
EUROTEST 600 |
|
|
Class ISO 7500-1 |
0.5 From 0.5% to 100% FS |
|||||
|
Maximum load |
50 kN 100 kN |
200 kN |
250 kN 300 kN |
400 kN |
500 kN |
600 kN |
|
Load measurement |
Universal strain-gage load cell (tension-compression) |
|||||
|
Force resolution |
0.0001 kN |
|||||
|
Load cell Repeatibility |
0.025% |
|||||
|
Horizontal clearance |
500 mm |
650 mm |
720 mm |
|||
|
Vertical clearance, distance between standard gripping heads
|
Adjustable between 0 and 1300 mm |
Adjustable between 0 and 1400 mm |
||||
|
Displacement speed |
From 0.001 to 1000.00 mm/min (other speeds on demand) |
From 0.001 to 500.00 mm/min |
||||
|
Displacement measurement |
Encoder (digital pulse sensor) |
|||||
|
Displacement resolution |
0.1 micron |
|||||
|
GENERAL CHARACTERISTICS |
||||||
|
Dimensions: Testing frame (mm) |
1020 x 650 x 2450mm (width x depth x height) |
1200 x 650 x 2900 mm |
1550 x 690 x 2900 mm (width x depth x height) |
|||
|
Approx weight ( without gripping heads ) |
1000 kg |
1200 kg |
1400 kg |
2900 kg |
||
|
Power supply |
3x 380 V + N+ T, 50/60 Hz |
|||||
