Feed Pellet Conditioner Machine
| Brand | Viteral |
|---|---|
| Model Type |
VCO-D 600 |
Description
Viteral VCO-D 600
600 MM Feed Pellet Conditioner Machine
Viteral VCO-D 600 Technical Specifications
| Model | Main Motor | Feeder Motor | Rotor Diameter | Weight |
| VCO-S 275 | 5.5 | 0.75 | 255 | 375 |
| VCO-S 450 | 11 | 2.2 | 450 | 975 |
| VCO-S 600 | 18.5 | 3 | 600 | 1470 |
| VCO-D 450 | 2×11 | 2.2 | 450 | 1550 |
| VCO-D 600 | 2×18.5 | 3 | 600 | 2435 |
| Model | A | B | C | D | E | F | G | H | I | J | ØK | K | L |
| VCO-S 275 | 2460 | 680 | 950 | 1340 | 450 | 1200 | 440 | 530 | 345 | 180 | – | 192 | 192 |
| VCO-S 450 | 3425 | 1080 | 1200 | 2780 | 1290 | 480 | 650 | 450 | 270 | 470 | – | – | |
| VCO-S 600 | 3390 | 1240 | 1420 | 3365 | 700 | 1430 | 500 | 800 | 520 | 320 | 620 | – | – |
| VCO-D 450 | 3425 | 1080 | 1850 | 2780 | 450 | 1290 | 480 | 650 | 450 | 270 | 470 | – | – |
| VCO-D 600 | 3390 | 1240 | 2220 | 3365 | 700 | 1430 | 500 | 800 | 520 | 320 | 620 | – | – |
