Gasket Casting Machine
| Brand | Teknofinsteel |
|---|---|
| Model Type |
Robosim 0735 Universal |
Polyurethane Gasket Casting Machine Universal Technical Specifications:
Rubber foam gasket sealing Machine
Pu sealing Machine gasket Machine
Pu gasket dispensing Machine
Polyurethane gasket seal Machine
Pu gasket sealing Machine
Pugasketing Machine
Pu polyurethane foam sealing
Best pu gasket sealing Machine
Automatic sealing foam
- POLYURETHANE GASKET CASTING MACHINES
- Polyurethane Gasket Casting Machine Single Table
- Polyurethane Gasket Casting Machine Double Table
- Polyurethane Gasket Casting Machine Universal
- Polyurethane Gasket Casting Machine Robotic
- Silicone Casting Machine
- Polyurethane Gasket Casting Chemicals
|
Specifications |
Polyurethane Gasket Casting Machine Universal |
| Machine Usage Dimensions |
2100x1200x900mm |
| Dosage Flow Rate |
2-10 kg/hour |
| Axis Speeds |
1m/min – 40m/min |
| Drive Type |
Robotic |
| Number of Tables |
1 – 3 |
| Weight |
200 – 280 kg |
| Control System |
Robotic 6 axis controlled |
| Programming |
Tutorial programming |
| Motor Types |
absolute |
| Reducer |
Robotic |
| Temperature Control System |
Standard |
| Number of Polyols |
1 – 2 (automatic transition) |
| Automatic Filling System |
Optional |
| Automatic Cleaning System |
Standard |
| Manual Pneumatic Cleaning System |
Standard |
| Load cell raw material consumption tracking |
Standard |
| Circulating Casting Head |
Standard |
| Electrical Power |
5.3 kW |
| Feeding Voltage |
220/380V 50 Hz |
| Air Consumption |
35 CFM |
| Decorative Coated Dosage System |
Standard |
| Polyol Tank Mixing System |
Reducer AC motor |
| Circulating Casting Head |
Servo motor driven mixer |
| Polyol Tank Capacity |
Stainless steel, double-walled, 35 kg |
| Isocyanate Tank Capacity |
Stainless steel, double-walled, 45 kg |
| Solvent Tank Capacity |
Stainless steel, 30 kg |
