ID1600 Indirectly Heated Thermoplastic Preheater and PS15 Power Unit

ID1600 Borum Thermoplastic Preheater
They are seamless equipment produced for heating thermoplastic materials in block, granule, and liquid form.
Thanks to the vertical type double-wing mixing arms, it provides homogeneous temperature distribution throughout the material. The Preheater is driven by the PS15 Hydraulic Power Unit, which is placed in a separate position from the tank. The standard length of the connection hoses is 6 meters. The heating system is a 12 V DC Powered Diesel Burner.

Indirect Heating System Preheater (ID)
It has features such as a hydromotor-driven mixer, START, STOP, and Reverse Operation valve for mixer drive, double arm and wing vertical mixer, a diathermic oil jacket surrounding the paint chamber, and a diathermic oil heated pipe located in the middle of the paint tank.
For temperature control, there are two separate thermostats that control the diathermic oil and paint temperature between +50 and +300° C; and two separate temperature indicators showing the temperatures of the paint and diathermic oil.

PS-15 Hydraulic Power Unit
Motor Power: 9.5 kW (13 hp) @ 3600 rpm. Water Cooling System, 2-cylinder Diesel Engine.
40 Liter capacity Diesel tank and filter.

12 V DC/65 Amp alternator,
Vibration damped motor base.
90 Liter capacity hydraulic oil tank
