Longlife Lnf-Sfp-10G-Lr 10Gbase-Lr Sfp+ 1310Nm 10Km Dom Duplex For Cisco

Cisco LNF-SFP-10G-LR Compatible 10GBASE-LR SFP+ Transceiver Module (SMF, 1310nm, 10km, LC, DOM)

The Cisco LNF-SFP-10G-LR compatible SFP+ transceiver supports connection distances of up to 10 km over LC duplex SMF fiber. This transceiver is compliant with SFF-8431, SFF-8432, and IEEE 802.3ae standards. Digital Optical Monitoring (DOM/DDM) is supported via a 2-wire serial interface as specified in SFF-8472. This 10G SFP+ transceiver offers low power consumption and high-speed capabilities, making it ideal for applications such as data centers, enterprise network switches, service provider transport applications, radio units, and baseband units.

Technical Specifications

• Cisco Compatibility: LNF-SFP-10G-LR

• Manufacturer: Longlife

• Form Factor: SFP+

• Maximum Data Rate: 10.3125 Gbps

• Wavelength: 1310 nm

• Maximum Cable Distance: 10 km

• Connector: Duplex LC

• Media: SMF

• Transmitter Type: DFB

• Receiver Type: PIN

• DDM/DOM: Supported

• Receiver Sensitivity: < -14.4 dBm

• TX Power: -8.2 ~ 0.5 dBm

• Receiver Overload: 0.5 dBm

• Power Budget: 6.2 dB

• Extinction Ratio: > 3.5 dB

• Power Consumption: ≤1W

• Operating Temperature Range: 0 ~ 70°C (32 ~ 158°F)

• Supported Protocols: IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432

• Warranty: 2 Years
