Longline Ağ Anahtarı Katman3 10G Yönetilen Anahtar Lng5720-8X

Longline Network Switch Layer3 10G Managed Switch LNG5720-8X

Longline LNG5720-8X is a high-performance and reliable Layer 3 managed switch that provides 10G Ethernet connectivity support. This device offers a fast and flexible solution for data transmission with its 10 Gigabit Ethernet connections. It meets the high-speed and reliability requirements in network infrastructure, making it an ideal choice for large network projects.

Applicable Standards:

• IEEE 802.3: 10BaseT

• IEEE 802.3u: 100BaseT

• IEEE 802.3ab: 1000BaseT

• IEEE 802.3z: 1000Base-SX

• IEEE 802.3ae: 10GBase-SR/LR

• IEEE 802.3x: Flow Control

Switching Features:

• Back Plane Bandwidth: 256 Gbps

• MAC Address Table: 32K

• Management Level: Layer 3 Managed (Static routing, RIP, OSPF and VLAN support)

Port Features:

• 10G SFP+ Ports: 8 x 10GBase-SR/LR (Fiber connection with SFP+ modules)

• Automatic speed adaptation, Full/Half duplex mode, MDI/MDI-X support

LED Indicators:

• PWR (Power)

• L/A (Link/Activity)

Power Supply Requirements:

• Input Voltage: AC 100-240V (Single power input)

• Power Consumption: Not specified

Physical Specifications:

• Casing: Metal case

• Dimensions: 440 x 300 x 44 mm

• Mounting Method: Rack mount type

Environmental Conditions:

• Operating Temperature: 0 ~ 50°C

• Storage Temperature: -10 ~ 70°C

• Relative Humidity: 5% ~ 95% (non-condensing)

Standards and Certification:

• Electromagnetic Compatibility (EMC):

  • IEC 61000-4-2 (ESD): Level 4

  • IEC 61000-4-4 (EFT): Level 4

  • IEC 61000-4-5 (Surge): Level 4

• Mechanical Durability:

  • Vibration: IEC 60068-2-6

  • Shock: IEC [ PHONE HIDDEN ]

  • Free Fall: IEC 60068-2-32
