Longline Network Switch 100G QSFP28 Data Center Switch LNG6670-32QC

Longline LNG6670-32QC is a powerful Layer 3 data center switch designed for core and distribution layers of data centers, offering high-density 100G connection support. It provides maximum performance in large-scale enterprise networks with low latency, high bandwidth needs, and scalable design. With its sturdy metal casing, advanced routing protocols, and powerful backplane capacity, it offers superior solutions for heavy traffic workloads.

Applicable Standards:

IEEE 802.3: 10BaseT
IEEE 802.3u: 100BaseT
IEEE 802.3ab: 1000BaseT
IEEE 802.3ae: 10GBase-SR/LR
IEEE 802.3ba: 40G/100G Ethernet
IEEE 802.3x: Flow Control

Switching Features:

Back Plane Bandwidth: 3.2 Tbps
MAC Address Table: 64K
Management Level: Layer 3 Managed (Static routing, RIP, OSPF, BGP, and VLAN support)

Port Features:

32 x 100G QSFP28 port
Auto speed adaptation, Full duplex mode, MDI/MDI-X support

LED Indicators:

PWR (Power)
L/A (Link/Activity)

Power Requirements:

Input Voltage: AC 100-240V
Power Supply Structure: Dual redundant power supply support
Power Consumption: Not specified

Physical Specifications:

Chassis: Metal casing
Dimensions: 440 x 350 x 44 mm
Mounting Method: Rack mount type

Environmental Conditions:

Operating Temperature: 0 ~ 50°C
Storage Temperature: -10 ~ 70°C
Relative Humidity: 5% ~ 95% (non-condensing)

Standards and Certifications:

Electromagnetic Compatibility (EMC):

IEC 61000-4-2 (ESD): Level 4
IEC 61000-4-4 (EFT): Level 4
IEC 61000-4-5 (Surge): Level 4

Mechanical Durability:

Vibration: IEC 60068-2-6
Shock: IEC [ PHONE HIDDEN ]
Free Fall: IEC 60068-2-32
