Longline Network Switch Layer3 2.5G Managed Switch Lng5860-48M4x2q

Longline Network Switch Layer3 2.5G Managed Switch LNG5860-48M4X2Q

The Longline LNG5860-48M4X2Q is a high-performance and reliable Layer 3 managed gigabit ethernet access switch that offers 2.5G connection support. This device provides strong performance and flexibility in large-scale network infrastructures. With fiber and copper connection options, it is an ideal choice for wide network solutions.

Applicable Standards:

• IEEE 802.3: 10BaseT

• IEEE 802.3u: 100BaseT

• IEEE 802.3ab: 1000BaseT

• IEEE 802.3bz: 2.5GBase-T

• IEEE 802.3x: Flow Control

Switching Features:

• Back Plane Bandwidth: 256 Gbps

• MAC Address Table: 32K

• Management Level: Layer 3 Managed (Static routing, RIP, OSPF, and VLAN support)

Port Features:

• RJ45 Ports: 48 × 2.5GBase-T

• SFP Slots: 4 × 1000Base-X SFP

• Automatic speed adaptation, Full/Half duplex mode, MDI/MDI-X support

LED Indicators:

• PWR (Power)

• L/A (Link/Activity)

Power Supply Requirements:

• Input Voltage: AC 100-240V (Single power input)

• Power Consumption: Not specified

Physical Specifications:

• Chassis: Metal casing

• Dimensions: 440 × 300 × 44 mm

• Mounting Method: Rack mount type

Environmental Conditions:

• Operating Temperature: 0 ~ 50°C

• Storage Temperature: -10 ~ 70°C

• Relative Humidity: 5% ~ 95% (non-condensing)

Standards and Certifications:

• ElectroMagnetic Compatibility (EMC):

  • IEC 61000-4-2 (ESD): Level 4

  • IEC 61000-4-4 (EFT): Level 4

  • IEC 61000-4-5 (Surge): Level 4

• Mechanical Durability:

  • Vibration: IEC 60068-2-6

  • Shock: IEC [ PHONE HIDDEN ]

  • Free Fall: IEC 60068-2-32
