Mold Preparation, Grading, Cake Placement and Drawing System

DIGIT

Mold input module (Photo digit)

 Mold fixing table and plate,

 Camera (Image capturing unit)

 Inter-module for reading general standard formats such as DXF, AAMA, ASTM, ISO

Mold input module (Digital)

 Completely independent mold input program

 Ability to enter the model as main body or complete series

 Real-time monitoring of the input process on the screen

 Ability to transfer a mold to the computer with all details (inner lines, marks, embroidery locations, etc.)

 Ability to add forgotten information to the same mold later on

OPTITEX MOLD DESIGN SOFTWARE (PDS)

Technical Specifications:

Compatible with all known CAD systems.

Data exchange with optional converter modules.

(AAMA, DXF, ASTM, ZIP and many more formats)

Compatible with all known DIGITIZER units.

Pattern cutting up to [ PHONE HIDDEN ] cm wide.

General Features:

Drawing functions that enable drawing all kinds of dress patterns from scratch

(curved, straight, angular lines of desired length)

Easy-to-use special functions for extracting welt, sample, applique, marking, and drawing patterns

Enhanced functions for pleats, tucks, gathers, drapes, spirals, flounces

One-command functions for adding seam allowances to all patterns, organizing seam corners,

and adding or removing smart seam allowance functions

Editing mold dimensions (batch lengthening-shortening, bringing the mold to the desired size and shaping commands)

Dimension and control functions (all kinds of distance measurement, comparison, alignment, folding, tracking and control of molds)

Reporting functions (sending data to MS Office programs)

Grading
