Ozco CA10040M Heavy Duty Diameter Lathe Machine
| Brand | Ozco |
|---|---|
| Model Type |
CA10040M |
Description
| Motor Power | 11 kW, 400 V |
|---|---|
| Table Diameter | 1000 mm |
| Carriage Diameter | 680 mm |
| Table Width | 600 mm |
| Distance Between Centers | 4000 mm |
| Maximum Load Capacity | 2000 kg |
| Speed | 6-750 (forward) / 10-775 (reverse) rpm |
| Gear | 21 (forward) / 12 (reverse) |
| Spindle Taper | MK6 |
| Spindle Nose | C11 |
| Spindle Diameter | 100 / 140 mm in L models |
| Cross Support Movement | 440 mm |
| Cross Slide Movement | 200 mm |
| Quill Taper | MK5 |
| Quill Diameter | 100 mm |
| Quill Movement | 250 mm |
| Linear Feed | 0.1-24.32 ; 64 mm/rev |
| Cross Feed | [ PHONE HIDDEN ] mm/rev |
| Metric Pitch and Ratio | 1-240 mm |
| Inch Pitch and Ratio | 1-14 |
| Module Pitch and Ratio | 0.5-120 mm |
| Diametral Pitch and Ratio | 1-28 |
| Tool Size (max.) | 32×32 mm |
| Machine Size | 6230x1730x1570 mm |
| Weight | 7250 kg |
- Compliant with CE norms
- Mechanical clutch system
- Heavy, solid cast iron machine base
- Joystick for easy movement
- Lighting system
- Cooling unit
- Tool guard and coolant tray
- Foot brake
