Ozco Fm20vld Desktop Router Table
| Brand | Ozco |
|---|---|
| Model Type |
FM20VLD |
Description
| Motor Power | 750 W, 220 V |
|---|---|
| Drilling Capacity | 16 mm |
| Finger Milling Capacity | 20 mm |
| Surface Milling Capacity | 63 mm |
| Table Dimensions | 700×180 mm |
| X Axis Movement | 480 mm |
| Y Axis Movement | 175 mm |
| Z Axis Movement | 270 mm |
| T Slot Size | 3×12 mm |
| Spindle Taper | MK2 |
| Spindle Speed | 50-2250 rpm |
| Speeds | 2 / Variable |
| Quill Movement | 50 mm |
| Head Tilt Angle | ± 45° |
| Spindle-Column Distance | 185 mm |
| Machine Dimensions (WxDxH) | 950x560x930 mm |
| Net Weight | 115 kg |
- 3 Axis digital coordinate reader
- Right/Left rotation feature
- Variable speed adjustment (stepless), digital speed indicator
- Height adjustable safety
- Switchable windshield
- Digital depth gauge
- ±45˚ head angle
- Compliant with CE standards
